NEMA 4X steel electrical box, 50x50x15 cm, IP66, waterproof and dustproof, outdoor/indoor

The NEMA 4X steel electrical box is designed to protect electrical equipment from dust, water, and other external factors. With an IP66 rating and rugged construction, this box is suitable for both outdoor and indoor use. Product dimensions and materials ensure reliable long-term use.

Description:

• Steel NEMA 4X housing with IP66 resistance level.
• Designed for outdoor and indoor electrical connection protection.
• Internal dimensions: 49.7 x 49.7 x 11.65 cm.
• External dimensions: 50 x 50 x 15 cm.
• Color: gray-white (RAL7035).
• Complete with mounting plate.

Features:

• Water and dust resistant, meets IP66 standard.
• Protection with hinges and lock.
• Material - carbon steel, thickness 1.5 mm.
• Epoxy and polyester powder coating provides corrosion protection.
• Easy to install and operate.
• Meets NEMA 1, 2, 4, 4X and 12 standards.

Technical data:

• Model: SPT.
• Product weight: 14.4 kg (31.75 lbs).
• Mounting plate: removable, galvanized, thickness 2 mm, dimensions 45 x 45 cm.
• Connector: hinges.
• CE and ROHS certificates.

Delivery set:

• NEMA 4X steel electrical box 50 x 50 x 15 cm.
• Removable galvanized mounting plate.
