Hydraulic pump and motor 21.2 GPM 540 RPM 2250 PSI for wood splitters

The 21.2 GPM hydraulic pump is designed to provide high performance and reliable operation in various hydraulic systems, such as log splitters, truck tail lifts and scissor lifts. The pump has high pressure and power, suitable for use in heavy industrial equipment.

Description:

• The hydraulic pump is designed for log splitters, truck tail lifts and scissor lifts.
• The pump is constructed with a reinforced iron housing to ensure durability in working conditions.
• A powerful hydraulic motor operating at 540 rpm. speed.
• Pressure limiting up to 2500 PSI, allowing for efficient hydraulic flow control.

Features:

• Fast and powerful operation, ensuring high efficiency.
• No fluid leakage due to sealed housing design.
• Widely used in various hydraulic systems.
• Flow 21.2 GPM at 540 rpm.

Technical data:

• Speed: 540 rpm.
• Shaft: 1-3/8" with 6-tooth female spline.
• Inlet: SAE 16.
• Outlet: SAE 12.
• Max. pressure: 2500 PSI.
• Displacement: 9.76 cu. in. / rpm.
• Pump type: gear.
• Mounting: 2 bolts on the side of the torque arm.
• Package weight: 45 lbs.
• Size: 6-3/8" x 6-3/4" x 8-3/4".

Package includes:

• Hydraulic pump 21.2 GPM with all applicable mounting hardware.
